Tsis Siv Neeg TIG Inner Hole Cladding Tshuab

Tsis siv neeg TIG puab qhov cladding tshuab

I. Welding Requirement

• Txhawm rau ua kom tiav qhov tsis siv neeg sab hauv qhov overlay vuam ntawm cov yeeb nkab / raj. Xyuas kom meej tias daim ntawv yog zoo ib yam thiab muaj ib tug zoo tsos, qhov tob ntawm fusion thiab dav ntawm fusion raws li qhov yuav tsum tau vuam, yooj yim rau clamp.

• Lub tshuab tuaj yeem ua haujlwm tsis tu ncua rau 24-teev.
• Cov khoom siv: stainless hlau, carbon hlau
• suav nrog cua txias system
• Lub tshuab no kuj tuaj yeem siv rau saum npoo av



II. Khoom Feature



Tsis siv neeg TIG puab qhov cladding tshuab:



1. Vuam teeb txav mus rau pem hauv ntej- rov qab nrog rau axis thiab welds workpiece. Workpiece yog rotating, vuam txoj hauj lwm yog kab rov tav.
2. Workpiece kev sib hloov yog tsav los ntawm lub hwj chim lub taub hau, kawg lub ntsej muag positioning, rotary vuam.
3. Nws txais kev thawb hom hlau pub hom kom lav qhov ruaj khov ntawm cov hlau pub.
4. Vuam teeb tuaj yeem hloov kho longitudinal kom haum rau ntau yam vuam hom.
5. PLC tswj tag nrho cov haujlwm. Kev sib hloov ceev ntawm workpiece yog kho los ntawm A / C inverter, stepless hloov, los txhim kho kev ntseeg siab ntawm cov khoom.
6. Vuam teeb tuaj yeem hloov kho nce thiab nqis, sab mus rau sab thiab tig tig kom tau raws li qhov xav tau vuam.



III.Technique Parameters

Siv tau vuam ntev	Max 1000 hli
Siv tau welding txoj kab uas hla	50.8-300 hli
Hom yeeb nkab	Hollow
Kev sib hloov ceev	0.2-2r.p.m
Lub cev muaj zog	0.75 kWm
Weld torch lifting range	Raws li max txoj kab uas hla ntawm workpiece
Txoj kab uas hla	1.2mm-2.4 hli
Tshuab ua hauj lwm voltage	380V 3phase 50hz rau vuam fais fab 220V ib theem rau lub ntsiab tshuab



IV.Equipment Composition

Tshuab lub cev adopts welded lub cev. Lub hauv paus tshuab yog welded los ntawm square raj thiab steel phaj. Nws yuav xaiv annealing kub kho tom qab vuam. Kem thiab boom, kev sib hloov axis lub thawv thiab lub ntsej muag kawg lub ntsej muag muab tso rau hauv lub hauv paus tshuab.

1.Cov yeeb nkab yog clamped los ntawm rotary chuck thiab txhawb los ntawm bracket ntawm dov lub log. Qhov deb ntawm cov brackets tuaj yeem hloov kho raws li cov yeeb nkab ntev.

2.Rotation Axis Box muaj AC zaus lub cev muaj zog, reducer, fixture thiab conductive lub tes tsho thiab lwm yam khoom. Kev sib hloov ceev yog hloov los ntawm kev tswj tus tsav tsheb kom hloov lub cev muaj zog. Lub workpiece tig yog clamped los ntawm chuck. Lub tes tsho conductive txais lub tes tsho tooj liab hloov tau, kev sib txuas ntawm lub tes tsho tooj liab thiab cov khoom ua haujlwm yog elastic. Cov roj conductive yog nchuav ntawm lub tes tsho tooj liab thiab cov khoom ua haujlwm, tiv thaiv - puas thiab hluav taws xob zoo.

3.Welding Torch Clamping&Adjustment Forward- Rov qab Mechanism: Lub vuam teeb yog txav mus rau pem hauv ntej- rov qab, tsav los ntawm lub servo lub cev muaj zog, kom paub qhov hloov ntawm kev npaj thiab vuam chaw nres tsheb. Lub vuam hluav taws xob siv lub tshuab thawb hlau los xyuas kom ruaj khov hlau noj. Lub vuam teeb tuaj yeem hloov kho nce thiab nqis, sab laug thiab sab xis thiab tig tig. Kev hloov kho zoo ntawm lub vuam teeb siv lub cev muaj zog-tsav nce thiab nqis zoo hloov kho hom thiab ntsia hlau hloov kho, raug kho kom raug, qhov chaw siab.



4.Siv tshwj xeeb customized TIG vuam torch kom tau raws li qhov yuav tsum tau ntawm xws li me me txoj kab uas hla.

V. Cov duab nthuav dav



Tsis siv neeg TIG puab qhov claddingtshuab:



Sab hauv qhov cladding tshuab TIG welding nyhuv zaub:

VI.Vedo rau koj siv



Tsis siv neeg TIG puab qhov cladding tshuab
